The main feature of the high pressure mist spray system is that it breaks through the traditional dust suppression method, eliminating the dust collection, pipeline transportation and dust post-treatment process. Control the dust directly at the dust location, and control the dust from the source. Micro mist dust suppression is suitable for any industrial and mineral dust of any nature.



The function, performance and dust suppression effect of the mist dust suppression system are much better than all kinds of traditional dust suppression equipment, energy saving and environmental protection, small water consumption and low operating costs.

Mist dust suppression device is mainly composed of: control system, induction device, air compressor, high efficiency spray box, water gas connection pipeline and so on.



Mist dust removal characteristics: dry fog treatment is less than 1-10 microns of scary dust, each material transfer point through reasonable design, reasonable configuration of spray amount. The droplets are injected to fill the material transfer point and have enough residence time to attract dust particles in the air and adsorb them to fall on the running boredom, turning the fog surface into a blanket to cover the dust. In developed countries, many major ports apply the ability to mimic nature to control dust, which is the use of dry fog suppression technology, to spray means to control dust. Wet Dust Solutions offers two dust control technologies based on these properties.



Energy saving: The use of dry mist non-wetting materials, unlike traditional water spray or chemical spray systems, it just moistens the dust in the air. This is the ideal solution for dust control, humidity sensitive materials such as coal, coke, gold and silver ore, etc. Water added less than 0.02% by weight, the mist system does not require any chemicals, can break the surface tension of water, micron unique nozzle design can continuously and efficiently produce 1-10 micron dry fog droplets, agglomeration and binding dust particles in the air, so that dust particles become sufficient mass. It lands on its own speed. It is also a drop cleaning technology that uses moist, foggy air to encase dust in a controlled environment.

The main advantages are:

1, the coverage area is large, can control 1000-6000 square
2, high working efficiency, fast dust removal speed
3, strong filtration system, two-stage filter
4, the whole computer automation operation
5, stable performance, long service life
6, low energy consumption, simple cost
7, wide range of application, can adapt to various operating environments
8, installation, simple operation
9, double effect, summer dust and cooling


Application detailed classification: coal mine, coal washing plant, steel plant, coal coking plant and other coal shed pile material shed dust removal, dust reduction and other fields

The function of the spray system: for the dust removal and dust suppression in the coal yard material shed, and the dust suppression efficiency is high, the treatment effect is good for the inhalable dust below 10 microns, effectively reduce the internal dust concentration after the coal yard is completely closed, and prevent the risk of explosion! Achieve green production, environmental protection production.

When the diameter of the water droplets is larger than the dust particles, the dust only follows the airflow around the water droplets, and the water droplets and the dust particles have little or no contact, which cannot achieve the effect of dust suppression. If the size of the fog beads and dust particles is close to each other, the surface tension of the water will be reduced, and it is easy to make the dust particles and fog droplets collide, contact and bond together. As the particle size of the droplets gets smaller and smaller, the probability of condensation becomes larger and larger, and the "filtering" effect of water mist on the dust is formed.

The high-pressure micro-fog dust suppression system directly pressurizes the water to 80 ~ 150kg/cm3, and the water is ejected from the equipment in the form of micro-fog (water fog particles with a diameter of <10μm) under the action of high pressure. When the water mist particles and dust particles are the same size, the water mist particles and dust particles are easy to cluster together, start to settle under the action of gravity, and then fall to the ground.

When a large number of small water droplets form a fog, completely covering the dust point, it will achieve a very good dust suppression effect. The micro-fog dust suppression system uses high pressure to turn the water mist into a water mist below 10μm, forming a fog above the dust point to completely cover the dust point, so that when the material is dusting, the dust completely enters the fog, fully combines with the water mist, and gradually increases, falling to the ground under the action of gravity.
